€525.00 ex. VAT 19%
NEW Raymarine’s Ray63 radio comes with oversized controls and a big screen for easy operation offshore. Ray63 is a full-function VHF marine radio with Class D Digital Selective Calling (DSC) and a built-in GPS receiver. The Ray63 also supports 1 wired or 2 wireless RayMic controllers for true multi-station control and intercom capability.
| E70516 | Ray63 VHF Radio (optional 2nd handset) with Integrated GPS receiver | € 525,00 |
| Environmental specifications | |
|---|---|
| Operating Temperature | -20ºC (-4ºF) to +60ºC (140ºF) |
| Storage Temperature | -25ºC (-13ºF) to +70ºC (158ºF) |
| Relative Humidity | 95% |
| Water Proofing | IPx6 & IPx7 |
| Connections | 1x NMEA 0183 | 1x SeaTalkng ® / NMEA 2000 | 1x Front Fistmic connection | 1x Rear connection for 2nd station | 1x Audio (RCA) | 1x GNSS (GPS) antenna (TNC) |
| Power | |
| Nominal Supply Voltage | 12V DC (Reverse polarity and over voltage protection) |
| Operating Voltage Range | 9V DC to 16V DC |
| Current Consumption | Less than 6A at high power (13.6 V) Standby: 600mA Receive: 2A |
| Transmitter | |
| Channels | All available US, International and Canadian VHF marine bands |
| Frequency Range | 156.000 – 157.425 MHz , 155.500 to 161.425 MHz Private channels |
| Frequency Stability | + / – 1.5 ppm |
| Channel Spacing | 12.5 kHz |
| Power Output | High Power = 25 Watt | Low Power = 1 Watt |
| Spurious emission | Better than -36 dBm at 25W (Less than 0.25 µW) |
| Maximum Deviation | +/- 5kHz |
| Antenna port impedance | 50 ohms typical |
| Receiver | |
| Receiver Type | Double Conversion Super Heterodyne |
| Channels | All available US, International and Canadian VHF marine bands |
| Frequency Range | 156.050 MHz to 163.275 MHz / 155.500 MHz to 161.425 MHz (Private channels) |
| Sensitivity | Better than 1 microvolt EMF @ 20dB SINAD |
| Squelch Sensitivity | Less than -2 dBµ EMF |
| Hum & Noise | Better than -40 dB |
| Audio Distortion | Less than 10% |
| Receiver Sensitivity | Distance -119 dBm (0.25uV)@12 dB SINAD ← Typical Local -110 dBm (0.7uV)@12 dB SINAD ← Typical |
| Adjacent Channel Selectivity | More than 70 dB |
| Spurious Response Rejection | More than 70 dB |
| Inter Modulation Rejection | More than 70 dB |
| Speakers | |
| Base Station Speaker Power Output | 2.5W (8Ω) |
| Fistmic Speaker Power | 1W (16Ω) |
| External Speaker Power | 5W (4Ω) / 2.5W (8Ω) |
| GNSS (GPS) | |
| Number of channels | 72 |
| Cold Start | <2 minutes |
| Receiver IC Sensitivity | -167 dBm (Tracking) / -148 dBM (Acquisition) |
| GNSS Compatibility | GPS | GLONASS | *BeiDou |
| SBAS Compatibility | WAAS | EGNOS | MSAS |
| Special Features | Active jamming and interference reduction |
| Operating Frequencies | GPS L1 C/A | GLONASS L10F | Beidou B1 |
| Signal Acquisition | Automatic |
| Almanac Update | Automatic |
| Geodetic Datum | WGS-84 (alternatives available through Raymarine MFD) |
| Refresh Rate | 10 Hz (10 times per second concurrent GNSS) |
| Antenna | Internal — Ceramic chip mounted near top of unit External — Passive antenna connection via TNC connector |
| Positional Accuracy | Without SBAS: <=15 metres 95% of the time With SBAS: <5 metres 95% of the time |
