Sale!


NEW Ray53 COMPACT VHF RADIO WITH GPS

395.00 290.00 ex. VAT 19%

NEW Raymarine’s Ray53 radio is small in size but big on features and performance. Ray53 is a full-function VHF marine radio with Class D Digital Selective Calling (DSC) and a built-in GPS receiver. Simply program your boat’s MMSI number into the Ray53 and immediately benefit from the enhanced calling and safety features of DSC.

Key Features

  • Compact marine VHF with Digital Selective Calling
  • Built-in GPS/GNSS receiver with a connection point for an optional external antenna
  • NMEA2000 and NMEA0183 networking for integration with onboard systems
  • Audio output connection for optional passive remote speaker (A80542)
  • Surface and trunnion mount kits included
  • Styled to compliment the Axiom family of multifunction displays



Ordering Information

Ray53 COMPACT VHF RADIO WITH GPS

In stock Part No. Description Price ex. VAT 19%
5 E70524 Ray53 VHF Radio with Integrated GPS € 290.00

Specifications



Environmental specifications
Operating Temperature -20ºC (-4ºF) to +60ºC (140ºF)
Storage Temperature -25ºC (-13ºF) to +70ºC (158ºF)
Relative Humidity 95%
Water Proofing IPx6 & IPx7
Connections 1x NMEA 0183 | 1x SeaTalkng ® / NMEA 2000 | 1x Audio (RCA) | 1x GNSS (GPS) antenna (TNC)
Power
Nominal Supply Voltage 12V DC (Reverse polarity and over voltage protection)
Current Consumption 9V DC to 16V DC
Current Consumption Less than 6A at high power (13.6 V)
Standby: 600mA
Receive: 2A
Transmitter
Channels All available US, International and Canadian VHF marine bands
Frequency Range 156.000 – 157.425 MHz , 155.500 to 161.425 MHz Private channels
Frequency Stability + / – 1.5 ppm
Channel Spacing 12.5 kHz
Power Output High Power = 25 Watt | Low Power = 1 Watt
Spurious emission  Better than -36 dBm at 25W (Less than 0.25 µW)
Maximum Deviation  +/- 5kHz
Antenna port impedance  50 ohms typical
Receiver
Receiver Type Double Conversion Super Heterodyne
Channels All available US, International and Canadian VHF marine bands
Frequency Range 156.050 MHz to 163.275 MHz / 155.500 MHz to 161.425 MHz (Private channels)
Sensitivity Better than 1 microvolt EMF @ 20dB SINAD
Squelch Sensitivity Less than -2 dBµ EMF
Hum & Noise Better than -40 dB
Audio Distortion Less than 10%
Receiver Sensitivity Distance -119 dBm (0.25uV)@12 dB SINAD ← Typical
Local -110 dBm (0.7uV)@12 dB SINAD ← Typical
Adjacent Channel Selectivity More than 70 dB
Spurious Response Rejection More than 70 dB
Inter Modulation Rejection More than 70 dB
Speakers
Base Station Speaker Power Output 2.5W (8Ω)
Fistmic Speaker Power 1W (16Ω)
External Speaker Power 5W (4Ω) / 2.5W (8Ω)
GNSS (GPS)
Number of channels 72
Cold Start <2 minutes
Receiver IC Sensitivity -167 dBm (Tracking) / -148 dBM (Acquisition)
GNSS Compatibility GPS | GLONASS | *BeiDou
SBAS Compatibility WAAS | EGNOS | MSAS
Special Features Active jamming and interference reduction
Operating Frequencies GPS L1 C/A | GLONASS L10F | Beidou B1
Signal Acquisition Automatic
Almanac Update Automatic
Geodetic Datum WGS-84 (alternatives available through Raymarine MFD)
Refresh Rate 10 Hz (10 times per second concurrent GNSS)
Antenna Internal — Ceramic chip mounted near top of unit
External — Passive antenna connection via TNC connector
Positional Accuracy Without SBAS: <=15 metres 95% of the time
With SBAS: <5 metres 95% of the time
