DC THRUSTER BTQ 185 Ø 185 mm – Double counter – Rotating propellers – boat length from 8 – 15 m

€2,597.00–€4,162.50 ex. VAT 19%

Clear

Quick bow thrusters
Mooring is not always a straightforward operation, especially when beyond not ideal wind and sea conditions a scarce space availability adds up.
This is the reason why today bow thrusters have become a very common way to render manoeuvrability of the vessel practical and functional, through remote commands.
The model choice covers the needs of boats with a length from 8 to 30 metres and a thrust range from 20 to 400 KGF.

BTQ 185 – Double counter – Rotating propellers
• Double propellers made in sturdy composite material
• Recommended boat length from 8-15 m (26-49 ft)
• Solenoids protection carter in sturdy composite material
• Gearbox in bronze
• Zinc anode independent from the gearbox and hence easily replaceable
• Equipped with elastic coupling.

Ordering Information

DC THRUSTER BTQ 185 Ø 185 mm – Double counter – Rotating propellers – boat length from 8 – 15 m

Part No. Description Price ex. VAT 19%
BTQ1806512 Twin counter rotating props – 65KGF – 12V – Ø 185 mm – 3.3kW € 2,597.00
BTQ1806524 Twin counter rotating props – 65KGF – 24V – Ø 185 mm – 3.3kW € 2,597.00
BTQ1808512 Twin counter rotating props – 85KGF – 12V – Ø 185 mm – 4.3kW € 2,715.00
BTQ1808524 Twin counter rotating props – 85KGF – 24V – Ø 185 mm – 4.3kW € 2,715.00
BTQ1810512 Twin counter rotating props – 105KGF – 12V – Ø 185 mm – 6.3kW € 4,162.00
BTQ1810524 Twin counter rotating props – 105KGF – 24V – Ø 185 mm – 6.3kW € 4,162.00

Specifications



General specifications
Models BTQ1806512 BTQ1806524 BTQ1808512 BTQ1808524 BTQ1810512 BTQ1810524
Propulsion system Double propeller contra-rotating Double propeller contra-rotating Double propeller contra-rotating Double propeller contra-rotating Double propeller contra-rotating Double propeller contra-rotating
Tunnel Diameter 185 mm
7 9/32″		 185 mm
7 9/32″		 185 mm
7 9/32″		 185 mm
7 9/32″		 185 mm
7 9/32″		 185 mm
7 9/32″
Motor Power 3.3 kW 3.3 kW 4.3 kW 4.3 kW 6.3 kW 6.3 kW
Voltage 12 V 24 V 12 V 24 V 12 V 24 V
Thrust 65 Kgf (143.3 lbs) 65 Kgf (143.3 lbs) 85 Kgf (187.4 lbs) 85 Kgf (187.4 lbs) 105 Kgf (213.5 lbs) 105 Kgf (213.5 lbs)
Weight 18kg/39.7lbs 18,3kg/40.3lbs 18,3kg/40.3lbs 21,3kg/47,0lbs 28kg/61.7lbs 25,2kg/55.5lbs
Boat Size
 8 – 11 m
26 – 36 ft		 8 – 11 m
26 – 36 ft		 10 – 15 m
33 – 50 ft		 10 – 15 m
33 – 50 ft		 12 – 15 m
39 – 49 ft		 12 – 15 m
39 – 49 ft
