DC THRUSTER BTQ 140 Ø 140 mm – Single propeller – boat length from 7 – 9 m

€1,509.50–€1,560.50 ex. VAT 19%

Clear

Quick bow thrusters
Mooring is not always a straightforward operation, especially when beyond not ideal wind and sea conditions a scarce space availability adds up.
This is the reason why today bow thrusters have become a very common way to render manoeuvrability of the vessel practical and functional, through remote commands.
The model choice covers the needs of boats with a length from 8 to 30 metres and a thrust range from 20 to 400 KGF.

BTQ 140 – Single propeller
• Single propeller made in sturdy composite material
• Recommended boat length from 7-9 m (23-29 ft)
• Solenoids protection carter in sturdy composite material
• Gearbox in bronze
• Zinc anode independent from the gearbox and hence easily replaceable
• Equipped with elastic coupling.

Ordering Information

DC THRUSTER BTQ 140 Ø 140 mm – Single propeller – boat length from 7 – 9 m

Part No. Description Price ex. VAT 19%
BTQ1403012 1 single prop – 30KGF – 12V – Ø 140 mm – 1.5kW € 1,509.50
BTQ1404012 1 single prop – 40KGF – 12V – Ø 140 mm – 2.2kW € 1,560.50

Specifications



General specifications
Models BTQ 140-30 BTQ 140-40
Propulsion system single propeller single propeller
Tunnel Diameter 140 mm
5″ 1/2		 140 mm
5″ 1/2
Motor Power 1.5 kW 2.2 kW
Voltage 12 V 12 V
Thrust 30 Kgf (66.1 lbs) 40 Kgf (88.2 lbs)
Weight 11,8 kg
26 lbs		 12,4 kg
27.3 lbs
Boat Size (the indiction may vary according to the boat type)
 7 – 8,5 m
23 – 28 ft		 7 – 9,5 m
23 – 31 ft
