Solar Panel SW-22145 – 12V 30Wp, Black, 273 x 807 x 6 mm
€321.00 ex. VAT 19%
Ordering Information
| In Stock | Part No. | Description | Price ex. VAT 19% |
|---|---|---|---|
| TBA | SW-22145 | 12V 30Wp, Black, 273 x 807 x 6 mm | € 321,00 |
Specifications
| Designation | Value |
|---|---|
| Pmax | 50.0 Wp |
| Imax | 1.20 A |
| Umax | 41.67 V |
| Uoc | 49.8 V |
| Isc | 1.27 A |
| No of cells | 78 Stck. |
| Cell size | 69.0 x 52.0 |
| Laminate | ETFE/EVA/ETFE |
| Length | 772.0 mm |
| Width | 493.0 mm |
| Product weight | 2.6 kg |
| System Voltage | 24 V |
| Protection Class | IP68 |
| Base plate | ALU-Sandwich white |
| Cable outlet | Front side |
| Cable length | 3 m |
