Ordering Information
In Stock | Part No. | Description | Price ex. VAT 19% |
---|---|---|---|
TBA | TX-42039 | 12V 152 Wp 929 x 1590 mm 8.2 kg 8.80A | €1342,85 |
Specifications
Designation | Value |
---|---|
Pmax | 152 Wp |
Imax | 8 A |
Umax | 19 V |
Uoc | 22.8 V |
Isc | 8.8 A |
No of cells | 36 Stck. |
Cell size | 39.0 x 156.0 mm |
Laminate | ETFE/EVA/ETFE |
Length | 929.0 mm |
Width | 1590.0 mm |
Product weight | 8.2 kg |
System Voltage | 12 V |
Protection Class | IP68 |
Base plate | Alu-Sandwich weiss/white |
Cable outlet | Front side |
Cable length | 1 m |
