€1,189.00–€1,349.50 ex. VAT 19%
Eagle Windlass Series – Horizontal in hard-cote aluminium – Including solenoids unit
Eagle – E1
• Horizontal windlasses
• Base in anodized aluminum in hard oxide
• With and without drum
• Integrated sensor and magnet for chain counter
• Manual Free-Fall system
• IP66 watertight motor
Gypsy and Drum
Ø 90 mm / 3″ 35/64
Gypsy
6mm
Easy Installation
The vertical motor allows for extremely
simple and quick installation.
| Part No. | Description | Price ex. VAT 19% |
|---|---|---|
| E1_512 | 500 W – 12 V | € 1,189.00 |
| E1_512D | 500 W – 12 V – With drum Ø 90 mm | € 1,349.50 |
| General specifications | |
|---|---|
| Motor Power | 500 W |
| Motor Supply Voltage | 12 V |
| Maximum pull | 630Kg/1389lbs |
| Maximum working load | 250Kg / 551lbs |
| Working load | 80 Kg / 176 lbs |
| Current absorption at working load (after an initial period of use) | 90 A |
| Maximum chain speed (measurements taken with a gypsy for a 6 mm chain) | 22,2 m/min 72.8 ft/min |
| Maximum chain speed at working load (measurements taken with a gypsy for a 6 mm chain) | 16,5 m/min 53.1 ft/min |
| Weight (without drum) | 8,0 Kg/17.6 lbs |
| Weight (with drum) | 9,3 Kg/20.5 lbs |
