Ordering Information
SL156C Emergency VHF Antenna 0,4m
| In Stock | Part No. | Description | Price ex. VAT 19% |
|---|---|---|---|
| 5 | 5215-D | 3dB 0.9m, VHF SAIL BOAT -S/S whip, sailboat antenna, SO239 (UHF) connector in base, SS bracket | € 56.45 |
5215 Sail Boat VHF Antenna, 90cm 3dB
€70.00 ex. VAT 19%
3′ (0.9m) VHF Marine Band 3dB Gain
Communication performance over VHF marine frequencies is optimized with the master craftsmanship of this Classic 5215 Squatty Body®, built with extra bandwidth for all popular AIS transceivers. The lightweight, low-profile, stainless steel VHF antenna stands at 3′ tall and is designed for masthead mounting to enhance transmission quality.
• Designed specifically for VHF transceivers
• Sealed, tin-plated copper wire coil
• Stainless steel body and 36″ whip
• SO-239 connector
• Mount: Stainless steel “L” bracket supplied
Specifications
| Shakespeare 5215 Antenna Specifications | ||||||||
|---|---|---|---|---|---|---|---|---|
| Band | VHF Marine Band | |||||||
| Antenna Gain | 3dB | |||||||
| Max. Input Power | 50 watts | |||||||
| SWR | nominally 1.5:1 at 156.8 MHz | |||||||
| Bandwidth | 7 MHz within 2.0:1 VSWR | |||||||
| Ferrule | L-bracket and retaining nut, SO-239 connector | |||||||
| Polarity | Vertical | |||||||
| Impedance | 50 Ohms | |||||||
| DC Ground | No DC Ground – The antenna will read open on continuity test | |||||||
