Ordering Information
In Stock | Part No. | Description | Price ex. VAT 19% |
---|---|---|---|
TBA | SW-40163 | 12V 27 Wp 426 x 481 mm 1.4 kg 1.44A | €345,00 |
Specifications
Designation | Value |
---|---|
Pmax | 27.0 Wp |
Imax | 1.36 A |
Umax | 19.85 V |
Uoc | 24.1 V |
Isc | 1.44 A |
No of cells | 38 Stck. |
Cell size | 39.0 x 104.0 |
Laminate | ETFE/EVA/ETFE |
Length | 426.0 mm |
Width | 481.0 mm |
Product weight | 1.4 kg |
System Voltage | 12 V |
Protection Class | IP68 |
Base plate | ALU-Sandwich white |
Cable outlet | Front side |
Cable length | 3 m |
