WhisperPower Switched Mode technology ensures a minimal energy loss and the highest output quality.
MC 12/24-10 DC/DC CONVERTER, Common Ground
€120.00 ex. VAT 19%
DC-DC step-up converter MC 12-24 VDC 10 A with common negative. Provides a stable 24 VDC to devices while operating on a 12V battery. The Switched Mode technology ensures minimal energy loss and high output. Fully protected against overload and high ambient temperatures. Incompatible for parallel setup.
Ordering Information
MC 12/24-10 DC/DC CONVERTER
| 60110017 | MC 12/24-10 DC/DC CONVERTER, Common Ground | € 120,00 |
Specifications
| Specifications | |
|---|---|
| Converter type | Step up an voltage stabilizing |
| Input | |
| Nominal input voltage | 12 VDC |
| Input range, full output specifications | 9..18 VDC |
| Input range, no defects | 0..18 VDC |
| Output | |
| Nominal output voltage | 25 VDC |
| Voltage adjustment | None |
| Output accuracy | 3% |
| Output voltage ripple, peakpeak | 3% |
| Maximum output power | 300 W |
| Continue output power | 250 W |
| Maximum output current | 12 A |
| Continue output current at 40 C | 10 A |
| General | |
| Efficiency | >93% |
| No load consumption | <5 mA |
| Ambient operating temperature | -10 °C .. + 40 °C |
| Storage temperature | -25 °C .. + 85 °C |
| Operating humidity | 95% max, non-condensing |
| Galvanic insulation | Common negative |
| Cooling concept | Natural convection |
| Protections | |
| Overcurrent / short circuit | Yes / fuse |
| Over heat, shutdown | None |
| Mechanical | |
| Connections input/output, Faston max wire |
6 mm² |
| Enclosure Dimensions (HxWxD) | 50 x 126 x 88 mm |
| Mounting holes footprint | Dia 4 mm 58 x 118 |
| Weight | 360 gr |
| Protection class | IP20 |
| Enclosure no. | Frame 5 |
| Enclosure Material | Alu / ABS |
| Enclosure Colour | Black RAL 9011 |
| Comply to the following standards | EN61000-6-3 (EN55022) EN61000-6-2 (EN61000-2/3/4, EN61000-4- 3) LVD 73/23/EEC (EN60335-1), e4-95/54/EC, RoHS 2002/95/EC |
