GEL Power Cells 2V/ 210Ah – 2000Ah

337.001,916.00 ex. VAT 19%

In a WhisperPower system the battery has a central role: it is the energy tank, dictating when power sources (battery charging devices) should start to refill “the tank”. The selection of the right battery capacity and technology determines the functionality and durability of such systems. WhisperPower has been a supplier of premium batteries for over the past 20 years.

Clear

Batteries

Power storage – batteries as “energy storage”

What all Whisper Power batteries have in common:

• They are all sealed and maintenance free
• They are safe – no danger of electrolyte spill or gassing
• They can be installed at different angles
• They are non-hazardous and can be transported in airplanes
• They are shockproof, if the battery is damaged no liquid will come out
• They are designed for a large number of charge/ discharge cycles
• They are built to last for 5 – 10 years
• They are supplied through the WhisperPower network with appropriate charging devices
• Self discharge is limited, batteries can be stored for many months without charging
• Minor ventilation is needed in the location of instalment.

Ordering Information

GEL Power Cells 2V

40290035 GEL Power 2V Cells 2V/ 210Ah  €  337,00
40290037 GEL Power 2V Cells 2V/ 440Ah  € 525,00
40290038 GEL Power 2V Cells 2V/ 525Ah  € 589,00
40290040 GEL Power 2V Cells 2V/ 750Ah  € 648,00
40290041 GEL Power 2V Cells 2V/ 1000Ah  € 882,00
40290042 GEL Power 2V Cells 2V/ 1250Ah  € 1.76,00
40290043 GEL Power 2V Cells 2V/ 1500Ah  € 1.271,00
40290044 GEL Power 2V Cells 2V/ 1650Ah  € 1.513,00
40290045 GEL Power 2V Cells 2V/ 2000Ah  € 1.916,00

Specifications

TECHNICAL SPECIFICATIONS

Nominal voltage 2 VDC
Weight +/- 10% 120.0 kg
Dimensions lxwxh (mm) (excl. poles) 275 x 210 x 820
Terminal type 4 × M8
CHARGE / DISCHARGE PARAMETERS
Bulk charge voltage (V/cel) 2.42 VDC at 20°C
Float voltage (V/cel) 2.25 VDC at 20°C
Initial charge current (A) 600 A
Temperature ratio -4mv/cel/°C
Recommended discharge voltage for 10 hours discharge (V/cel) 1,80 VDC/cel
Recommended discharge voltage for 1 hour discharge (V/cel) 1,65 VDC/cel
