CAM210 Bullet CCTV Day and Night Video Camera (IP Connected)

€645.00 ex. VAT 19%

NEW CAM210
Day & Night Marine Camera
Ruggedised, High Definition, Day and Night network bullet video camera suitable for all above deck applications. Integrated sun-cover for maximum visibility and small frame size for easy installation anywhere on the boat.

Video Output: IP

Raymarine Visible Light Marine Cameras

Visible light marine cameras offer an affordable marine CCTV solution. They perform well across a variety of lighting conditions and manage motion well. Simply plug and play with any compatible Raymarine multifunction display (analogue cameras require a BNC composite video input connector) to create your onboard video observation system.

Key Features
• Plug and play integration with Raymarine MFD’s running Lighthouse II
• Power over Ethernet (PoE) or direct 12v DC power supply
• High bright IR LEDs for operation in total darkness
• Digital Defog processing improves the captured image in poor weather conditions (such as smog, fog or smoke)
• Intelligent IR technology for clear video images at night in all conditions

Ordering Information

CAM210 Bullet CCTV Day and Night Video Camera (IP Connected)

Part No. Description Price ex. VAT 19%
E70346 CAM210 Bullet CCTV Day and Night Video Camera (IP Connected) € 645.00

Specifications



General specifications
Description CAM210 IP Camera (Bullet)
System
CPU 32-bit ARM9 RISC CPU up to 432MHz
Flash / SDRAM 128MB / 128MB
Camera
Image Sensor 2.0 Megapixel 1/2.8″ SONY progressive scan CMOS(Exmor)
Total Pixels 1952(H) x 1116(V) 2.18 Megapixel
Effective Pixels 1944(H) x 1104(V) 2.15 Megapixel
S/N Ratio More than 50dB
Minimum Illumination 0Lux (IR On)
IR Distance 20m
Day&Night ICR
Lens 6.0mm Megapixel Board Lens
Field of view Diagonal = 63.6 deg +/- 3 deg | Horizontal = 33.1 deg +/- 3 deg | Vertical = 53.3 deg +/- 3 deg
Video
Video Compression H.264 High Profile@4.0, MJPEG –Image quality: 3 Steps
Resolution Up to 1920 x 1080 (Full HD)
Frame Rate H.264 Up to 30fps with 1920×1080 | MJPEG Up to 30fps with VGA resolution
Video Streaming Support multi stream with H.264, MJPEG
Adjustable frame rate
CVBR/CBR in H.264
Image Setting Day & Night | Auto White Balance | Auto Exposure | Privacy Mask | Effects – Colour, Sharpness, Mirror / V-Flip
System Integration
Security Password protection, User access log, HTTPS encryption
Supported Protocol HTTP, HTTPS, FTP, SMTP, UPnP, DNS, DDNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP
Intelligent Video Motion detection up to 1920×1080 with 4×3 blocks
Physical
Power Source DC12V/1.5A, PoE(Power over Ethernet): 802.3af
Power Consumption Max. 3.3W, Max. 5.3W with IR
Net Weight 900g
LED’s Power, Network Connection
Dimensions 83.8mm(W) x 155mm(H) x 178.1mm(D) including Bracket
General Operation Temperature 0 degree~40 degree Celsius(32F~104F)
Storage Temperature -10 degree~50 degree Celsius(14F~122F)
