€1,531.00–€1,724.50 ex. VAT 19%
Gypsy and Drum
Ø 130 mm / 5″1/8
| Part No. | Description | Price ex. VAT 19% |
| AL3P_1012 |
AL3 1012 WINDLASS 1000W 12V 08/10mm |
€ 1,531.00 |
| AL3P_1024 |
AL3 1024 WINDLASS 1000W 24V 08/10mm |
€ 1,587.00 |
| AL3P_1012D |
AL3 1012D WINDLASS 1000W 12V 08/10mm D |
€ 1,667.50 |
| AL3P_1024D |
AL3 1024D WINDLASS 1000W 24V 08/10mm D |
€ 1,724.50 |
| General specifications | ||
|---|---|---|
| Models | Aleph 1000 | Aleph 1000D |
| Motor Power | 700 W | 700 W |
| Motor Supply Voltage | 12 V | 24 V |
| Maximum Pull | 1000 Kg / 2204 lb | 1000 Kg / 2204 lb |
| Maximum Working Load | 370 Kg 816 lb |
450 Kg 992 lb |
| Working Load | 1120 Kg 264 lb |
150 Kg 331 lb |
| Current absorption at working load (after an initial period of use) | 140 A | 80 A |
| Maximum Chain Speed (measurements taken with a gypsy for a 6 mm chain) | 39,6 m/min 129.2 ft/min |
40,9 m/min 134.2 ft/min |
| Maximum Chain Speed at working load (measurements taken with a gypsy for a 6 mm chain) | 20,4 m/min 66.9 ft/min |
21,4 m/min 70.2 ft/min |
| Weight (without drum) | 17,5 Kg / 38.6 lb | 17,5 Kg / 38.6 lb |
| Weight (with drum) | 18,9 Kg / 41.7 lb | 18,9 Kg / 41.7 lb |
