The advantages offered by the DCS charge sepatators are:
• Input voltage up to 31Vdc
• S terminal for compensating separator voltage drop (in pre-set sources, battery chargers or alternators)
• Functioning over a wide range of environmental temperatures
• Installation and wiring facilitated by the compact design of the separator.
Ordering Information
Diode charge separator – 80A – 1 input – 3 outputs
In Stock | Part No. | Description | Price ex. VAT 19% |
---|---|---|---|
TBA | DCS 1083 | Diode charge separator – 80A – 1 input – 3 outputs | € 68.00 |
Specifications
General specifications | |
---|---|
Model | DCS 1083 |
Input Voltage | 31 Vdc |
Loss of voltage (typical values) | 0,7 Vdc |
Number of input | 1 |
Number of output | 3 |
Battery charger current (total maximum current divided over output points) | 60 A |
Charge current from alternator (total maximum current divided over output points) |
80 A |
Operating temperature | from – 20 to + 50 °C |
Cooling | Natural |
Dimensions W x H x D | 175 x 68 x 135 mm 6″ 57/64 x 2″ 43/64 x 5″ 5/16 |
Weight | 1090 g / 2,40 lb |
