P7 Shorty
Through-Hull
The plastic P7 isthe best performers in the Shorty™ Series designed for boats with limited headroom. Large, sensitive ceramics allow deeper echosounding. The low-profile P7 model is nearly flush and minimizes drag with only 5 mm (3/16″) extending outside of the hull.
Part Number:E26009
P319
Through-Hull
The P319 features our 50/200 kHz, dual-frequency, single-ceramic element in a low-profile housing. The nearly-flush design minimizes drag with only 5 mm (3/16″) extending outside of the hull. The bronze B117 and stainless steel SS60 models are also available to accommodate all hull materials.
Part Number:M78713-PZ
P17
Through-Hull
Depth only transducer compatible with aluminium and fibreglass hull materials. Cable 13.7m (45ft) cable with connector. Hole diameter for installation: 2″
Part Number: E26030
P66
Transom Mount
The P66 features a 50/200 kHz, dual-frequency, single-ceramic element. This hydrodynamic housing with a rounded nose reduces the turbulence under the transducer’s face for accurate high-speed readings and clear display images.
Part Number: E26027-PZ
P79
In-Hull
The P79 in-hull transducer easily adjusts to hull dead rise angles up to 22º. This ensures that the beam is vertically oriented to receive echoes, resulting in accurate depth readings. Unlike traditional “puck” type transducers, the P79 consists of a base that is bonded to the hull and filled with liquid. The separate transducer then attaches to the base with a twist lock. The sound waves travel more efficiently though the liquid, giving the best possible performance.
Part Number: E26001-PZ
B45
Through-Hull
The B45 is the smallest and most economical, dual-frequency, bronze, stem transducer. Its streamlined shape deflects aerated water from the transducer’s face for strong return echoes and clear display images. An Airmar High-Performance Fairing is recommended for all installations to get the best possible results.
Part Number: E26019-PZ
B17
Through-Hull
Depth only transducer compatible with wood and fibreglass hull materials. Features a retractable depth insert
Part Number: M78717
