AXIOM+ 9, Multi-function 9″ Display

1,495.00 ex. VAT 19%

A powerful new multifunction navigation system from Raymarine. The all new LightHouse 3 operating system, and blazing fast quad core performance, AXIOM will transform your time on the water.

AXIOM – Touch Screen Multifunction Navigation Displays
A powerful new multifunction navigation system from Raymarine. The all new LightHouse 3 operating system, and blazing fast quad core performance, AXIOM will transform your time on the water.

BLAZING FAST PERFORMANCE AND POWER AT YOUR FINGER TIPS

Axiom is expandable, so its capabilities can grow, as needed. It supports the full range of Raymarine accessories, including Quantum radar, CHIRP Sonar, FLIR thermal cameras, audio integration, instruments, cameras, and Evolution autopilot. Standard Wi-Fi and Bluetooth connectivity allows connection to the latest Raymarine apps for tablets and smartphones.
Axiom includes surface and trunnion mounting kits, mounting hardware, power/data cable, and installation instructions.

New LightHouse 3 OS is fast, fluid, and easy to learn. An uncluttered interface is easily personalized for your style of navigating.

Rugged all-glass display optimized for flush or surface mounting. Sleek buttonless design with swipe-to-power control.

Support for the best charts from Navionics and LightHouse Raster and Vector Charts sourced from leading map makers like NV Digital, Blue Latitude, and more.



Ordering Information

AXIOM 9, Multi-function 9″ Display


Part No. Description Price ex. VAT 19%
E70637 AXIOM+ 9, Multi-function 9″ Display €1495

Specifications



General specifications
Display Size 9.0″ Optically Bonded LCD
Display Resolution 800 x 480 WQVGA
Screen Type Touchscreen
Mounting Options Top / Flush / Bracket / Rear Mounting
Networking 1 x 10/100 Mbits/ Network (RayNet)
Waterproofing Standard IPX6 and IPX7
Memory Card Slots 1x MicroSD
Bluetooth Bluetooth 2.1 + EDR power class 1.5 (supports AVRCP 1.0)
Radar Compatible Yes
Thermal Night Vision Compatible Yes – compatible with FLIR M100 and M200 cameras
Video Cameras Optional
Built-in Sonar Model dependent
External Sonar Compatible Yes – support for Digital and CHIRP sonar modules
GPS Built-in GNSS Receiver: GPS/GLONASS/Beidou* – 10Hz 72 Channel
Optional Remote Controls RMK-10
AIS With optional receivers and transceivers
Autopilot Control Evolution Autopilot Integration
Digital Switching Empirbus compatible
Audio Integration Support for NMEA2000 compatible audio devices
Voltage 12V DC (8 V to 16 VDC)
Operating Temperature -13º F to +131º F (-25º C to +55º C)
