– 500 amp continue rating
– bi-stable or Auto Magnetic Latching draws n oor verry little current in the ON or Off states
– Manual override knob provides and added level of safety allowing control with or without power and offering Lock-off capability during maintenance
– Silver alloy contacts provide high reliability
– Multiple cable terminals by 22mm studs
– Ce marking, iso 8846
– SAEJ1171 external ignition protection requirements
– IP66 protected against powerful water jets
WP-Magnetic Latch Battery Switch, 500A/12-24V – incl remote switch
€376.00 ex. VAT 19%
When leaving the marina and heading for the ocean, you are getting fully dependent on your boat electrical system. With WhisperPower, you are secured electricity is guided into the appropriate conduits which prevents dangerous situations.The WhisperPower DC distribution program offers high quality components ensuring a safe and enjoyable trip.
When setting up the battery banks of your 12 or 24V system, the required capacity and choice of battery type are not the only important elements. Vital components around the battery are at least as important. WhisperPower provides you with all the necessary high quality components to perfectly round off your installation. WhisperPower offers a complete program of manual and remote operated battery switches.
Manual operated WP-Compact series or WP-Heavy Duty series, manual ON/OFF switches to connect/disconnect DC consumers and/or battery bank. Remote operated – WP-ML Bi-stable low current draw remote battery switch/magnetic latch, for remote ON and off switching of the DC consumers and/or battery bank.
Ordering Information
WP-Magnetic Latch Battery Switch, 500A/12-24V
| 50214731 | WP-Magnetic Latch Battery Switch, 500A/12V – incl remote switch | € 376,00 |
| 50214732 | WP-Magnetic Latch Battery Switch, 500A/24V – incl remote switch | € 376,00 |
Specifications
| INPUT | |
|---|---|
| Battery input | 1 |
| Switch Positions | 2 |
| Manual overide | Locked off/on |
| I 10 Cranking rating 10 sec | 2500A |
| I 60 Cranking rating 1 min | 1100A |
| I 300 Cintermittent rating 5 min | 700 A |
| I C continue rating | 500 A |
| Vmno Voltage maxium Operation | 32 VDC |
| Control Circuit Voltage | 10.1..16.5VDC |
| Operatiuon current continous | 0 mA |
| Operation current when charging | 7 A |
| Remote Control switch when charging | 100 mA |
| GENERAL SPECIFICATIONS | |
|---|---|
| Ambient operation temperature | -20 C … +40C |
| Storage temperature | -25 C … +85C |
| Operating humidity | 95%, non condens |
| Live current switching | 100.000 cyles |
| MECHANICAL | |
|---|---|
| Connections terminal stud | M10 (3/8’-.16) |
| Connections stud lenght | 23 mm |
| Maximum terminal Stud Torque | 15.5 NM (140 in-lb) |
| Terminal material | tin-plated copper |
| Enclosure width | 95.25 mm |
| Enclosure height | 138.94 mm |
| Enclosure depth | 51.56 mm |
| Weight | 0.8 kg |
| Drilling mounting centers | 114.3mm * 76.20mm |
| Mounting screws | 4 mm |
| Ingress Protection Class | IP66 |
| Enclosure Colour | RAL9011 Graphite Black |
| Cable clearance | 28.4 mm (1.12’) |
| Ignition Protection | SA J1171 |
| Markings | CE, Iso 8846 |
