The Seagull line offers a n updated selection of instruments and sensors expressly designed for nautical application allowing the monitoring of all basic engine and navigation variables. During the development of the seagull line our engineers considered all parameters including reliability, performance, design and easy operation with one main objective in mind: to offer you precisely what you were looking for. The seagull line, tested over fifteen years of presence in the market, has been chosen as original equipment by several shipbuilders and engine manufacturers.
Ordering Information
Synchronism engine speed indicator
In Stock | Part No. | Description | Price ex. VAT 19% |
---|---|---|---|
TBA | VSG12410 | SYNC INDICATOR RQ Ø85MM WHITE DIAL W- PCKUP 12/24V | €580.00 |
TBA | VSG12110 | SYNC INDICATOR RQ Ø85MM BLACK DIAL W- PCKUP 12/24V | €320.00 |
Specifications
General specifications | |
---|---|
Range | ±400 RPM |
Case diameter | Ø 85 mm |
Case diameter | Ø86. Mounting brackets |
Depth | 60 mm |
RQ series cover lens | Double lens anti-fog chamber |
Illumination | Red |
Housing | Nylon PA66 |
Connectors | 3 x RJ-45 High grade gold plated contacts |
Power supply | 9/32 VDC |
Power consumption | 100 mA max + backlighting |
Operating temperature | -25 +70° C |
Protection | IP66 on the front |
Electromagnetic compatibility | IEC60945 |
Vibration and shock resistance | IEC60945 |
