Synchronism engine speed indicator Ø 85mm

320.00580.00 ex. VAT 19%

The Seagull line offers a n updated selection of instruments and sensors expressly designed for nautical application allowing the monitoring of all basic engine and navigation variables.

Clear

The Seagull line offers a n updated selection of instruments and sensors expressly designed for nautical application allowing the monitoring  of all basic engine and navigation variables. During the development of the seagull  line our engineers considered all parameters including reliability, performance, design and easy operation with one main objective in mind: to offer you precisely what you were looking for. The seagull line, tested over fifteen years of presence in the market, has been chosen as original equipment by several shipbuilders and engine manufacturers.

Ordering Information

Synchronism engine speed indicator

In Stock Part No. Description Price ex. VAT 19%
TBA VSG12410 SYNC INDICATOR RQ Ø85MM WHITE DIAL W- PCKUP 12/24V €580.00
TBA VSG12110 SYNC INDICATOR RQ Ø85MM BLACK DIAL W- PCKUP 12/24V €320.00

Specifications

General specifications
Range ±400 RPM
Case diameter Ø 85 mm
Case diameter Ø86. Mounting brackets
Depth 60 mm
RQ series cover lens Double lens anti-fog chamber
Illumination Red
Housing Nylon PA66
Connectors 3 x RJ-45 High grade gold plated contacts
Power supply 9/32 VDC
Power consumption 100 mA max + backlighting
Operating temperature -25 +70° C
Protection IP66 on the front
Electromagnetic compatibility IEC60945
Vibration and shock resistance IEC60945
