MARINE WOOFERS (PRIME)

€125.00–€145.00 ex. VAT 19%

Clear

Subwoofer Features

  • Designed for high output capability
  • Torture tested to ensure long life and performance
  • Engineered for exposure to elements
  • Multiple sizes from 8″ to 12″

Ordering Information

MARINE WOOFERS (PRIME)

In Stock Part No. Description Price
TBA A80392 Prime M1 8″ DVC Speakers (2ohm) White €125
TBA A80393 Prime M1 8″ DVC Speakers (2ohm) Black €125
TBA A80394 Prime M1 8″ DVC Speakers (4ohm) White €125
TBA A80395 Prime M1 8″ DVC Speakers (4ohm) Black €125
TBA A80396 Prime M1 10″ DVC Speakers (2ohm) White €135
TBA A80397 Prime M1 10″ DVC Speakers (2ohm) Black €135
TBA A80398 Prime M1 10″ DVC Speakers (4ohm) White €135
TBA A80399 Prime M1 10″ DVC Speakers (4ohm) Black €135
TBA A80400 Prime M1 12″ DVC Speakers (2ohm) White €145
TBA A80401 Prime M1 12″ DVC Speakers (2ohm) Black €145
TBA A80402 Prime M1 12″ DVC Speakers (4ohm) White €145
TBA A80403 Prime M1 12″ DVC Speakers (4ohm) Black €145

Specifications



General specifications
Model PRIME M1 8″
2 Ohm		 PRIME M1 8″
4 Ohm		 PRIME M1 10″
2 Ohm		 PRIME M1 10″
4 Ohm		 PRIME M1 12″
2 Ohm		 PRIME M1 12″
4 Ohm		 PRIME M1 12″
4 Ohm
Part Number: A80392 (White)
A80393 (Black)		 A80394 (White)
A80395 (Black)		 A80396 (White)
A80397 (Black)		 A80398 (White)
A80399 (Black)		 A80400 (White)
A80401 (Black)		 A80402 (White)
A80403 (Black)		 PRIME M1 12″
4 Ohm
Size: 8″ 8″ 10″ 10″ 12″ 12″ 12″
Nominal Impedance: Dual 2-Ohm Dual 4-Ohm Dual 2-Ohm Dual 4-Ohm Dual 2-Ohm Dual 4-Ohm Dual 4-Ohm
Power Handling: 150 Watts RMS
300 Watts Max		 150 Watts RMS
300 Watts Max		 200 Watts RMS
400 Watts Max		 200 Watts RMS
400 Watts Max		 200 Watts RMS
400 Watts Max		 200 Watts RMS
400 Watts Max		 200 Watts RMS
400 Watts Max
Voice Coil Diameter: 1.5″ aluminum 1.5″ aluminum 2″ aluminum 2″ aluminum 2″ aluminum 2″ aluminum 2″ aluminum
Magnet Weight: 17.72 oz.
(0.50 Kg)		 17.72 oz.
(0.50 Kg)		 39.75 oz.
(1.13 Kg)		 39.75 oz.
(1.13 Kg)		 39.75 oz.
(1.13 Kg)		 39.75 oz.
(1.13 Kg)		 39.75 oz.
(1.13 Kg)
Speaker Connector: Dual 12 AWG compression Dual 12 AWG compression Dual 12 AWG compression Dual 12 AWG compressiont Dual 12 AWG compression Dual 12 AWG compression Dual 12 AWG compression
Woofer Displacement: 0.05 cu. ft. (1.41 Liters) 0.05 cu. ft. (1.41 Liters) 0.10 cu. ft. (2.80 Liters) 0.10 cu. ft. (2.80 Liters) 0.12 cu. ft. (3.49 Liters) 0.12 cu. ft. (3.49 Liters) 0.12 cu. ft. (3.49 Liters)
Cutout Diameter: 7.0 in. (177 mm) 7.0 in. (177 mm) 8.95 in. (227 mm) 8.95 in. (227 mm) 10.87 in. (276 mm) 10.87 in. (276 mm)
Mounting Depth: 3.6 in. (91.7 mm) 3.6 in. (91.7 mm) 4.4 in. (112 mm) 4.4 in. (112 mm) 4.81 in. (122 mm) 4.81 in. (122 mm)
SKU: N/A
