€7,211.50–€7,644.00 ex. VAT 19%
Duke Windlass Series – Vertical in anodized aluminium
Duke – DK6 XY
• Vertical windlasses
• Stainless steel Aisi 316 and anodized aluminium base
• Stainless steel Aisi 316 drum and gypsy cover
• With and without drum
• Integrated sensor and magnet for chain counter
• Safety mechanical band brake
• Anodized aluminium gearbox
Gypsy and Drum
Ø 200 mm / 7″ 7/8
Gypsy
12-13 mm | 14 mm – 1/2″ | 16 mm
| Part No. | Description | Price ex. VAT 19% |
|---|---|---|
| DK6 3024X | 3000 W – 24 V – Right chain pipe | € 7,211.50 |
| DK6 3024DX | 3000 W – 24 V – Right chain pipe – With drum Ø 200 mm | € 7,644.00 |
| General specifications | |
|---|---|
| Models | DK6 3024X DK6 3024DX |
| Motor Power | 3000 W |
| Motor Supply Voltage | 24 V |
| Maximum pull | 3000Kg/6614lbs |
| Maximum working load | 1200Kg/2646lbs |
| Working load | 600 Kg/1323 lbs |
| Current absorption at working load (after an initial period of use) | 173 A |
| Maximum chain speed (measurements taken with a gypsy for a 12/13 mm chain) | 31,0 m/min 101.7 ft/min |
| Maximum chain speed at working load (measurements taken with a gypsy for a 12/13 mm chain) | 15,1 m/min 49.5 ft/min |
| Weight (withut drum) | 110Kg/203.9lbs |
| Weight (with drum) | 93,5Kg/206.1lbs |
