€5,103.00–€5,482.50 ex. VAT 19%
Dave Windlass Series – Vertical Windlasses
Dave – DV5 XY
• Vertical windlasses
• Stainless steel Aisi 316 base and anodized aluminium
• With and without drum
• Rope and chain on a single gypsy
• Integrated sensor and magnet for chain counter
• Manual Free-Fall system
• Safety mechanical band brake
• Supplied with pressure lever
• Inspection cover
• Motor watertight to IP66
• Anodized aluminium gearbox
Gypsy and Drum
Ø 170 mm / 6″21/64
Gypsy
10 mm – 3/8″ | 12/13 mm | 14 mm
Rope
3/4″ (19 mm) | 3/4″ (19 mm) | 3/4″ (19 mm)
| Part No. | Description | Price ex. VAT 19% |
|---|---|---|
| DV5 3024X | 3000 W – 24 V – Right chain pipe | € 5,103.00 |
| DV5 3024DX | 3000 W – 24 V – Right chain pipe – With drum Ø 170 mm | € 5,482.50 |
| General specifications | |
|---|---|
| Motor Power | 3000 W |
| Motor Supply Voltage | 24 V |
| Maximum pull | 3100 Kg / 6834 lbs |
| Maximum working load | 1200 Kg / 2646 lbs |
| Working load | 400 Kg / 882 lbs |
| Current absorption at working load (after an initial period of use) | 145 A |
| Maximum chain speed | 39,2 m/min 128.6 ft/min |
| Maximum chain speed at working load | 19,3 m/min 63.3 ft/min |
| Weight (without drum) | 61,3 Kg / 135.1 lbs |
| Weight (with drum) | 64,7 Kg / 142.6 lbs |
