Dorsal™ VHF Antenna

The new Shakespeare DORSAL™ antenna range was designed specifically for greater effectiveness in short-range applications.  The fin shaped design removes the chance of the antenna getting snagged while the high impact and sealed ABS body ensures a longer life within harsh environments.

  • Low profile fin shaped antenna
  • Compact design, 4” x 2.3” x 2.5”
  • Suitable for up to 10 miles range
  • Supplied with 26ft RG58 cable and PL-259 plug standard
  • Fully water sealed with rubber gasket included
  • 2-year warranty
  • Models:
    • 5912-DS-VHF-W (White)
    • 5912-DS-VHF (Black)

Ordering Information

Dorsal™ VHF Antenna

Part No.

Description

 Price ex. VAT 19%
5912-DS-VHF DORSAL™ Low profile fin shaped VHF antenna with 26ft RG58 cable and PL-259 plug standard € 70.00

Specifications

 DORSAL™ Antenna Specifications
Band VHF Marine Band
Antenna Gain 0dB
Max. Input Power 25 watts
SWR nominally 1.5:1 at 156.8 MHz
Bandwidth 7 MHz within 2.0:1 VSWR
Ferrule Chrome plated brass cannister
Coax Supplied 15 ft of RG-58
Connector Supplied PL-259, not installed
Polarity Vertical
Impedance 50 Ohms
DC Ground No DC Ground – The antenna will read open on continuity test
