Solar Panel TX-14152 – 12V 17 Wp 750 x 275 mm 1.0 kg 1.00 A
€293.27 ex. VAT 19%
Ordering Information
| In Stock | Part No. | Description | Price ex. VAT 19% |
|---|---|---|---|
| TBA | TX-11027 | 12V 17 Wp 668 x 333 mm 1.0 kg 1.00A | €259,66 |
Specifications
| Designation | Value |
|---|---|
| Pmax | 17.0 Wp |
| Imax | 0.90 A |
| Umax | 18.89 V |
| Uoc | 22.8 V |
| Isc | 1.00 A |
| No of cells | 36 Stck. |
| Cell size | 52.0 x 52.0 mm |
| Laminate | ETFE/EVA/ETFE |
| Length | 750.0 mm |
| Width | 275.0 mm |
| Product weight | 1 kg |
| System Voltage | 12 V |
| Protection Class | IP68 |
| Base plate | Alu-Sandwich weiss/white |
| Cable outlet | Front side |
| Cable length | 3 m |
